| Input | |||||
| Network Video Input | 4-CH | ||||
| Bandwidth Requirement | 40Mbps (Incoming)40Mbps (Outgoing) | ||||
| Output | |||||
| HDMI Output | 1-CH, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz. (HDMI supports Audio Output) | ||||
| Dual Stream | Support | ||||
| Recording Resolution/ | Synchronous Playback | *The recommended parameters are theoretical values only. Actual performance may vary depending on the usage environment, the number of connected cameras, and their models. | *Resolutions with width or height >4096 not supported for decoding. | When the bite rate is ≤2048 kbps: | 1*(30fps @8MP), 1*(30fps @6MP), 1*(30fps @5MP), 2*(30fps @4MP), 2*(30fps @3MP), 4*(30fps @1080P), 4*(30fps @720P) |
| Format | |||||
| Video Compression | H.265+/H.265(HEVC)/H.264+/H.264 | *H.265 decoding is supported with performance limitations depending on stream settings. | System performance may vary based on bitrate, resolution, and number of channels. | ||
| Audio Compression | G.711/AAC/G.722/G.726 | ||||
| Sample Rate | 8KHz/16KHz | ||||
| Storage | |||||
| SATA | 1*SATA HDD (3.5”) | ||||
| Capacity | Up to 10TB capacity for each HDD | ||||
| Record | |||||
| Recording Type | Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis) | ||||
| Playback Type | General Playback, Event Playback, Tag Playback, Split Playback, Picture Playback | ||||
| Backup | Video backup, Image Backup | ||||
| Network | |||||
| Network Protocols | IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS | ||||
| Interface | |||||
| Network Interface | 1*RJ45 10/100Mbps | ||||
| USB Interface | 2*USB 2.0 | ||||
| General | |||||
| Compatibility | ONVIF, API | ||||
| Advanced Function | ANR | ||||
| Video Analysis | Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, People Counting, Object Left, Object Removed | ||||
| Keyboard Control | Milesight Keyboard(MS-K01) | ||||
| Power Supply | DC 12V 2A | ||||
| Consumption | ≤2.3W(Without HDD) | ||||
| Working Conditions | Temperature: -10℃∼+55℃ / Humidity: 10%∼90% | ||||
| Dimensions | 220mm(W)X200mm(D)X43.6mm(H) | ||||
| Weight | 0.19Kg | ||||
| Warranty | 3/5 Years |
